The Z97 chipset is hidden beneath a small metallic heatsink which is definitely not the design we will be looking at on the final retail models.
Storage slots include 8 SATA 6 GB/s ports and a USB 3.0 header right next to them.
#Msi z97 gaming 7 motherboard internal speaker connectoor series
Expansion slots include three PCI-E 3.0 x16, four PCI-E 3.0 x1 and the M.2 interface to support Intel's NGFF (Next Generation Form Factor) 530 Series SSDs. There are four Dual Channel DDR3 DIMM slots which will support overclocked memory upto 2666 MHz+ (O.C) frequencies. Power to the socket is pumped through a 8-PIN power connector while the regular 24-PIN ATX connector is used to power the board itself. The Z97 Gaming 7 looks like a feature packed board with a 12 20 Phase DigitALL Power Design and the latest LGA1150 socket which will support the Haswell and Haswell Refresh processors. MSI will also offer Z97 motherboards under their XPower and Legacy brand but we don't have any information on those at the current moment.
The two boards we are looking at include the Z97 Gaming 7 and Z97 Gaming 3 so its not hard to assume that these will be part of MSI's next generation Z97 Gaming motherboard lineup. The Z97 motherboards showcased by MSI are bare prototypes and lack the heatsinks which will be featured on the final retail models. Image is courtesy of VR-Zone! MSI Shows Off Next Generation Z97 Motherboards Prototypes Recently, HardwareLuxx managed to get a first look at MSI's upcoming Z97 motherboards prototypes which were displayed at an NDA briefing by the hardware manufacturer.
Intel is just a month away from launching their latest Haswell Refresh platform which would be compatible with the next generation 9-Series chipset compatible H97 and Z97 Motherboards.
